AT Cylindrical Axial
- It has a circular section with a diameter of 315-1400
- Connecting the electric motor and propeller directly
- It has a 3-phase motor in the form of 4 poles, 6 poles
- Motorclass F
- IP55 degree of protection
fans with diameters 315-1400 mm, are designed for installation in commercial and industrial ventilation systems and supply of car park areas. The propeller is made from aluminum and the cylinder is made from steel and protected by a paint finish. The connection of fan propeller and the motor is direct. Motors are from credible Euro-pean brand and are available in three phase 380V-50Hz with 2 and 4 poles. The fan is equipped with a class F low Energy consumption motor. The fan protection Class is IP55. Three phase motors are suitable for inverter control. AT cylindrical axial fans are designed for installation in commercial and industrial facilities, workshops, ware-house, ducts, and supply air of car park areas.
| Short Case | ||||||
|---|---|---|---|---|---|---|
| Product Code | A | B | C | D | E | Hole Number |
| AT-315 | 315.00 | 384.00 | 12.00 | 350.00 | 200.00 | 8.00 |
| AT-355 | 355.00 | 424.00 | 12.00 | 390.00 | 200.00 | 8.00 |
| AT-400 | 400.00 | 486.00 | 12.00 | 450.00 | 250.00 | 8.00 |
| AT-450 | 450.00 | 537.00 | 12.00 | 500.00 | 250.00 | 8.00 |
| AT-500 | 500.00 | 594.00 | 12.00 | 560.00 | 250.00 | 12.00 |
| AT-560 | 560.00 | 655.00 | 12.00 | 630.00 | 280.00 | 12.00 |
| AT-630 | 630.00 | 724.00 | 12.00 | 690.00 | 280.00 | 12.00 |
| AT-710 | 710.00 | 806.00 | 12.00 | 770.00 | 380.00 | 16.00 |
| AT-800 | 800.00 | 986.00 | 12.00 | 860.00 | 380.00 | 16.00 |
| AT-900 | 900.00 | 1004.00 | 15.00 | 970.00 | 900.00 | 16.00 |
| AT-1000 | 1000.00 | 1104.00 | 15.00 | 1070.00 | 1000.00 | 16.00 |
| AT-1120 | 1120.00 | 1224.00 | 15.00 | 1190.00 | 1120.00 | 20.00 |
| AT-1250 | 1250.00 | 1354.00 | 15.00 | 1320.00 | 1250.00 | 20.00 |
| LONG CASE | ||||||
|---|---|---|---|---|---|---|
| Product Code | A | B | C | D | E | Hole Number |
| AT-315 | 315.00 | 384.00 | 12.00 | 350.00 | 300.00 | 8.00 |
| AT-355 | 355.00 | 424.00 | 12.00 | 390.00 | 300.00 | 8.00 |
| AT-400 | 400.00 | 486.00 | 12.00 | 450.00 | 380.00 | 8.00 |
| AT-450 | 450.00 | 537.00 | 12.00 | 500.00 | 480.00 | 8.00 |
| AT-500 | 500.00 | 594.00 | 12.00 | 560.00 | 480.00 | 12.00 |
| AT-560 | 560.00 | 655.00 | 12.00 | 630.00 | 600.00 | 12.00 |
| AT-630 | 630.00 | 724.00 | 12.00 | 690.00 | 600.00 | 12.00 |
| AT-710 | 710.00 | 806.00 | 12.00 | 770.00 | 600.00 | 16.00 |
| AT-800 | 800.00 | 986.00 | 12.00 | 860.00 | 600.00 | 16.00 |
| AT-900 | 900.00 | 1004.00 | 15.00 | 970.00 | 750.00 | 16.00 |
| AT-1000 | 1000.00 | 1104.00 | 15.00 | 1070.00 | 780.00 | 16.00 |
| AT-1120 | 1120.00 | 1224.00 | 15.00 | 1190.00 | 1150.00 | 20.00 |
| AT-1250 | 1250.00 | 1354.00 | 15.00 | 1320.00 | 1150.00 | 20.00 |
| TECHNICAL CHARACTERISTICS-2 POLES | ||||||
|---|---|---|---|---|---|---|
| Model | Diameter (mm) | Motor Power (kW) | Full load Current at 400V (A) | Weight (kg) | ||
| Short Casing | Long Casing | |||||
| AT-315-4/25-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-4/30-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-4/35-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-4/40-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-4/45-2T0.75-F300 | 315.00 | 0.75 | 1.73 | 13.00 | 15.00 | |
| AT-315-4/45-2T1.1-F300 | 315.00 | 1.10 | 2.40 | 15.00 | 17.00 | |
| AT-315-8/25-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-8/30-2T0.55-F300 | 315.00 | 0.55 | 1.36 | 10.00 | 12.00 | |
| AT-315-8/35-2T0.75-F300 | 315.00 | 0.75 | 1.73 | 13.00 | 15.00 | |
| AT-315-8/40-2T0.75-F300 | 315.00 | 0.75 | 1.73 | 13.00 | 15.00 | |
| AT-315-8/40-2T1.1-F300 | 315.00 | 1.10 | 2.40 | 15.00 | 17.00 | |
| AT-315-8/45-2T1.1-F300 | 315.00 | 1.10 | 2.40 | 15.00 | 17.00 | |
| AT-355-4/25-2T0.55-F300 | 355.00 | 0.55 | 1.36 | 10.50 | 12.00 | |
| AT-355-4/30-2T0.55-F300 | 355.00 | 0.55 | 1.36 | 10.50 | 12.00 | |
| AT-355-4/35-2T0.75-F300 | 355.00 | 0.75 | 1.73 | 13.50 | 15.00 | |
| AT-355-4/35-2T1.1-F300 | 355.00 | 1.10 | 2.40 | 15.50 | 17.00 | |
| AT-355-4/40-2T1.1-F300 | 355.00 | 1.10 | 2.40 | 15.50 | 17.00 | |
| AT-355-4/45-2T1.1-F300 | 355.00 | 1.10 | 2.40 | 15.50 | 17.00 | |
| AT-355-8/25-2T0.75-F300 | 355.00 | 0.75 | 1.73 | 13.50 | 15.00 | |
| AT-355-8/30-2T0.75-F300 | 355.00 | 0.75 | 1.73 | 13.50 | 15.00 | |
| AT-355-8/30-2T1.1-F300 | 355.00 | 1.10 | 2.40 | 15.50 | 17.00 | |
| AT-355-8/35-2T1.1-F300 | 355.00 | 1.10 | 2.40 | 15.50 | 17.00 | |
| AT-355-8/40-2T1.5-F300 | 355.00 | 1.50 | 3.25 | 17.40 | 18.90 | |
| AT-355-8/45-2T1.5-F300 | 355.00 | 1.50 | 3.25 | 17.40 | 18.90 | |
| AT-400-4/25-2T0.55-F300 | 400.00 | 0.55 | 1.36 | 14.50 | 18.00 | |
| AT-400-4/30-2T0.75-F300 | 400.00 | 0.75 | 1.73 | 17.50 | 21.00 | |
| AT-400-4/30-2T1.1-F300 | 400.00 | 1.10 | 2.40 | 19.50 | 23.00 | |
| AT-400-4/35-2T1.1-F300 | 400.00 | 1.10 | 2.40 | 19.50 | 23.00 | |
| AT-400-4/40-2T1.5-F300 | 400.00 | 1.50 | 3.25 | 21.40 | 24.90 | |
| AT-400-4/45-2T1.5-F300 | 400.00 | 1.50 | 3.25 | 21.40 | 24.90 | |
| AT-400-4/45-2T2.2-F300 | 400.00 | 2.20 | 4.55 | 24.20 | 27.70 | |
| AT-400-8/25-2T1.1-F300 | 400.00 | 1.10 | 2.40 | 19.50 | 23.00 | |
| AT-400-8/30-2T1.5-F300 | 400.00 | 1.50 | 3.25 | 21.40 | 24.90 | |
| AT-400-8/35-2T2.2-F300 | 400.00 | 2.20 | 4.55 | 24.20 | 27.70 | |
| AT-400-8/40-2T2.2-F300 | 400.00 | 2.20 | 4.55 | 24.20 | 27.70 | |
| AT-450-4/25-2T1.1-F300 | 450.00 | 1.10 | 2.40 | 20.50 | 27.00 | |
| AT-450-4/30-2T1.1-F300 | 450.00 | 1.10 | 2.40 | 20.50 | 27.00 | |
| AT-450-4/35-2T1.5-F300 | 450.00 | 1.50 | 3.25 | 22.40 | 28.90 | |
| AT-450-4/35-2T2.2-F300 | 450.00 | 2.20 | 4.55 | 25.20 | 31.70 | |
| AT-450-4/40-2T2.2-F300 | 450.00 | 2.20 | 4.55 | 25.20 | 31.70 | |
| AT-450-4/45-2T3-F300 | 450.00 | 3.00 | 6.10 | 31.50 | 38.00 | |
| AT-450-8/25-2T1.5-F300 | 450.00 | 1.50 | 3.25 | 22.40 | 28.90 | |
| AT-450-8/30-2T2.2-F300 | 450.00 | 2.20 | 4.55 | 25.20 | 31.70 | |
| AT-450-8/35-2T3-F300 | 450.00 | 3.00 | 6.10 | 31.50 | 38.00 | |
| AT-450-8/40-2T3-F300 | 450.00 | 3.00 | 6.10 | 31.50 | 38.00 | |
| AT-500-4/25-2T1.1-F300 | 500.00 | 1.10 | 2.40 | 22.00 | 29.00 | |
| AT-500-4/30-2T1.5-F300 | 500.00 | 1.50 | 3.25 | 23.90 | 30.90 | |
| AT-500-4/35-2T2.2-F300 | 500.00 | 2.20 | 4.55 | 26.70 | 33.70 | |
| AT-500-4/40-2T3-F300 | 500.00 | 3.00 | 6.10 | 33.00 | 40.00 | |
| AT-500-4/45-2T4-F300 | 500.00 | 4.00 | 7.80 | 40.00 | 47.00 | |
| AT-500-8/25-2T2.2-F300 | 500.00 | 2.20 | 4.55 | 26.70 | 33.70 | |
| AT-500-8/30-2T3-F300 | 500.00 | 3.00 | 6.10 | 33.00 | 40.00 | |
| AT-500-8/35-2T4-F300 | 500.00 | 4.00 | 7.80 | 40.00 | 47.00 | |
| AT-500-8/40-2T4-F300 | 500.00 | 4.00 | 7.80 | 40.00 | 47.00 | |
| AT-560-3/20-2T2.2-F300 | 560.00 | 2.20 | 4.55 | 28.90 | 39.70 | |
| AT-560-3/25-2T3-F300 | 560.00 | 3.00 | 6.10 | 35.20 | 46.00 | |
| AT-560-3/32.5-2T4-F300 | 560.00 | 4.00 | 7.80 | 42.20 | 53.00 | |
| AT-560-3/32.5-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-3/35-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-3/37.5-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-6/20-2T3-F300 | 560.00 | 3.00 | 6.10 | 35.20 | 46.00 | |
| AT-560-6/25-2T4-F300 | 560.00 | 4.00 | 7.80 | 42.20 | 53.00 | |
| AT-560-6/25-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-6/30-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-9/20-2T4-F300 | 560.00 | 4.00 | 7.80 | 42.20 | 53.00 | |
| AT-560-9/20-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-560-9/25-2T5.5-F300 | 560.00 | 5.50 | 10.40 | 52.20 | 63.00 | |
| AT-630-3/20-2T2.2-F300 | 630.00 | 2.20 | 4.55 | 30.70 | 43.70 | |
| AT-630-3/20-2T3-F300 | 630.00 | 3.00 | 6.10 | 37.00 | 50.00 | |
| AT-630-3/25-2T4-F300 | 630.00 | 4.00 | 7.80 | 44.00 | 57.00 | |
| AT-630-3/30-2T5.5-F300 | 630.00 | 5.50 | 10.40 | 54.00 | 67.00 | |
| AT-630-3/32.5-2T5.5-F300 | 630.00 | 5.50 | 10.40 | 54.00 | 67.00 | |
| AT-630-3/35-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| AT-630-3/37.5-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| AT-630-6/20-2T4-F300 | 630.00 | 4.00 | 7.80 | 44.00 | 57.00 | |
| AT-630-6/25-2T5.5-F300 | 630.00 | 5.50 | 10.40 | 54.00 | 67.00 | |
| AT-630-6/25-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| AT-630-6/30-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| AT-630-9/20-2T5.5-F300 | 630.00 | 5.50 | 10.40 | 54.00 | 67.00 | |
| AT-630-9/20-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| AT-630-9/25-2T7.5-F300 | 630.00 | 7.50 | 13.80 | 63.00 | 76.00 | |
| TECHNICAL CHARACTERISTICS-4 POLES | |||||||
|---|---|---|---|---|---|---|---|
| Model | Diameter (mm) | Motor Power (kW) | Full load Current at 400V (A) | MOTOR | Weight (kg) | ||
| Short Casing | Long Casing | ||||||
| AT-1000-3/32.5-4T3-F300 | 1000.00 | 3.00 | 6.40 | 24.00 | 76.00 | 105.00 | |
| AT-1000-3/35-4T3-F300 | 1000.00 | 3.00 | 6.40 | 24.00 | 76.00 | 105.00 | |
| AT-1000-3/37.5-4T3-F300 | 1000.00 | 3.00 | 6.40 | 24.00 | 76.00 | 105.00 | |
| AT-1000-3/37.5-4T4-F300 | 1000.00 | 4.00 | 8.20 | 31.00 | 83.00 | 112.00 | |
| AT-1000-3/40-4T4-F300 | 1000.00 | 4.00 | 8.20 | 31.00 | 83.00 | 112.00 | |
| AT-1000-3/40-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-3/42.5-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-3/45-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-3/47.5-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-3/47.5-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-3/50-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-6/25-4T3-F300 | 1000.00 | 3.00 | 6.40 | 24.00 | 76.00 | 105.00 | |
| AT-1000-6/27.5-4T4-F300 | 1000.00 | 4.00 | 8.20 | 31.00 | 83.00 | 112.00 | |
| AT-1000-6/30-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-6/32.5-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-6/32.5-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-6/35-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-6/37.5-4T11-F300 | 1000.00 | 11.00 | 21.50 | 73.00 | 125.00 | 154.00 | |
| AT-1000-6/37.5-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-6/40-4T11-F300 | 1000.00 | 11.00 | 21.50 | 73.00 | 125.00 | 154.00 | |
| AT-1000-6/42.5-4T11-F300 | 1000.00 | 11.00 | 21.50 | 73.00 | 125.00 | 154.00 | |
| AT-1000-6/45-4T15-F300 | 1000.00 | 15.00 | 28.50 | 85.00 | 137.00 | 166.00 | |
| AT-1000-6/47.5-4T15-F300 | 1000.00 | 15.00 | 28.50 | 85.00 | 137.00 | 166.00 | |
| AT-1000-6/50-4T15-F300 | 1000.00 | 15.00 | 28.50 | 85.00 | 137.00 | 166.00 | |
| AT-1000-6/50-4T18.5-F300 | 1000.00 | 18.50 | 35.50 | 113.00 | 165.00 | 194.00 | |
| AT-1000-9/25-4T4-F300 | 1000.00 | 4.00 | 8.20 | 31.00 | 83.00 | 112.00 | |
| AT-1000-9/25-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-9/27.5-4T5.5-F300 | 1000.00 | 5.50 | 11.40 | 41.00 | 93.00 | 122.00 | |
| AT-1000-9/30-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-9/32.5-4T7.5-F300 | 1000.00 | 7.50 | 15.20 | 49.00 | 101.00 | 130.00 | |
| AT-1000-9/35-4T11-F300 | 1000.00 | 11.00 | 21.50 | 73.00 | 125.00 | 154.00 | |
| AT-1000-9/37.5-4T11-F300 | 1000.00 | 11.00 | 21.50 | 73.00 | 125.00 | 154.00 | |
| AT-1000-9/40-4T15-F300 | 1000.00 | 15.00 | 28.50 | 85.00 | 137.00 | 166.00 | |
| AT-1000-9/42.5-4T15-F300 | 1000.00 | 15.00 | 28.50 | 85.00 | 137.00 | 166.00 | |
| AT-1000-9/45-4T18.5-F300 | 1000.00 | 18.50 | 35.50 | 113.00 | 165.00 | 194.00 | |
| AT-1000-9/47.5-4T18.5-F300 | 1000.00 | 18.50 | 35.50 | 113.00 | 165.00 | 194.00 | |
| AT-1000-9/50-4T22-F300 | 1000.00 | 22.00 | 41.50 | 123.00 | 175.00 | 204.00 | |
| AT-1120-4/25-4T4-F300 | 1120.00 | 4.00 | 8.20 | 31.00 | 94.00 | 162.00 | |
| AT-1120-4/25-4T5.5-F300 | 1120.00 | 5.50 | 11.40 | 41.00 | 104.00 | 172.00 | |
| AT-1120-4/27.5-4T5.5-F300 | 1120.00 | 5.50 | 11.40 | 41.00 | 104.00 | 172.00 | |
| AT-1120-4/30-4T7.5-F300 | 1120.00 | 7.50 | 15.20 | 49.00 | 112.00 | 180.00 | |
| AT-1120-4/32.5-4T7.5-F300 | 1120.00 | 7.50 | 15.20 | 49.00 | 112.00 | 180.00 | |
| AT-1120-4/35-4T11-F300 | 1120.00 | 11.00 | 21.50 | 73.00 | 136.00 | 204.00 | |
| AT-1120-4/37.5-4T11-F300 | 1120.00 | 11.00 | 21.50 | 73.00 | 136.00 | 204.00 | |
| AT-1120-4/40-4T15-F300 | 1120.00 | 15.00 | 28.50 | 85.00 | 148.00 | 216.00 | |
| AT-1120-4/42.5-4T15-F300 | 1120.00 | 15.00 | 28.50 | 85.00 | 148.00 | 216.00 | |
| AT-1120-4/45-4T15-F300 | 1120.00 | 15.00 | 28.50 | 85.00 | 148.00 | 216.00 | |
| AT-1120-4/45-4T18.5-F300 | 1120.00 | 18.50 | 35.50 | 113.00 | 176.00 | 244.00 | |
| AT-1120-4/47.5-4T18.5-F300 | 1120.00 | 18.50 | 35.50 | 113.00 | 176.00 | 244.00 | |
| AT-1120-4/47.5-4T22-F300 | 1120.00 | 22.00 | 41.50 | 123.00 | 186.00 | 254.00 | |
| AT-1120-4/50-4T22-F300 | 1120.00 | 22.00 | 41.50 | 123.00 | 186.00 | 254.00 | |
| AT-1120-8/25-4T7.5-F300 | 1120.00 | 7.50 | 15.20 | 49.00 | 112.00 | 180.00 | |
| AT-1120-8/27.5-4T11-F300 | 1120.00 | 11.00 | 21.50 | 73.00 | 136.00 | 204.00 | |
| AT-1120-8/30-4T11-F300 | 1120.00 | 11.00 | 21.50 | 73.00 | 136.00 | 204.00 | |
| AT-1120-8/32.5-4T15-F300 | 1120.00 | 15.00 | 28.50 | 85.00 | 148.00 | 216.00 | |
| AT-1120-8/35-4T15-F300 | 1120.00 | 15.00 | 28.50 | 85.00 | 148.00 | 216.00 | |
| AT-1120-8/35-4T18.5-F300 | 1120.00 | 18.50 | 35.50 | 113.00 | 176.00 | 244.00 | |
| AT-1120-8/37.5-4T18.5-F300 | 1120.00 | 18.50 | 35.50 | 113.00 | 176.00 | 244.00 | |
| AT-1120-8/37.5-4T22-F300 | 1120.00 | 22.00 | 41.50 | 123.00 | 186.00 | 254.00 | |
| AT-1120-8/40-4T22-F300 | 1120.00 | 22.00 | 41.50 | 123.00 | 186.00 | 254.00 | |
| AT-1120-8/42.5-4T22-F300 | 1120.00 | 22.00 | 41.50 | 123.00 | 186.00 | 254.00 | |
| AT-1120-8/42.5-4T30-F300 | 1120.00 | 30.00 | 55.00 | 157.00 | 220.00 | 288.00 | |
| AT-1120-8/45-4T30-F300 | 1120.00 | 30.00 | 55.00 | 157.00 | 220.00 | 288.00 | |
| AT-1120-8/47.5-4T30-F300 | 1120.00 | 30.00 | 55.00 | 157.00 | 220.00 | 288.00 | |
| AT-1120-8/50-4T30-F300 | 1120.00 | 30.00 | 55.00 | 157.00 | 220.00 | 288.00 | |
| AT-1120-8/50-4T37-F300 | 1120.00 | 37.00 | 66.00 | 206.00 | 269.00 | 337.00 | |
| AT-1250-4/24-4T15-F300 | 1250.00 | 15.00 | 28.50 | 85.00 | 155.00 | 230.00 | |
| AT-1250-4/26-4T15-F300 | 1250.00 | 15.00 | 28.50 | 85.00 | 155.00 | 230.00 | |
| AT-1250-4/26-4T18.5-F300 | 1250.00 | 18.50 | 35.50 | 113.00 | 183.00 | 258.00 | |
| AT-1250-4/28-4T18.5-F300 | 1250.00 | 18.50 | 35.50 | 113.00 | 183.00 | 258.00 | |
| AT-1250-4/28-4T22-F300 | 1250.00 | 22.00 | 41.50 | 123.00 | 193.00 | 268.00 | |
| AT-1250-4/30-4T18.5-F300 | 1250.00 | 18.50 | 35.50 | 113.00 | 183.00 | 258.00 | |
| AT-1250-4/30-4T22-F300 | 1250.00 | 22.00 | 41.50 | 123.00 | 193.00 | 268.00 | |
| AT-1250-4/30-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-4/32-4T22-F300 | 1250.00 | 22.00 | 41.50 | 123.00 | 193.00 | 268.00 | |
| AT-1250-4/32-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-4/34-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-4/34-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-4/36-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-4/36-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-4/36-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-4/38-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-4/38-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-4/40-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-4/40-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-4/40-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-4/42-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-4/42-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-4/44-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-4/44-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-4/44-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-4/46-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-4/46-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-4/48-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-4/48-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/24-4T22-F300 | 1250.00 | 22.00 | 41.50 | 123.00 | 193.00 | 268.00 | |
| AT-1250-8/24-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-8/26-4T22-F300 | 1250.00 | 22.00 | 41.50 | 123.00 | 193.00 | 268.00 | |
| AT-1250-8/26-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-8/28-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-8/28-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-8/30-4T30-F300 | 1250.00 | 30.00 | 55.00 | 157.00 | 227.00 | 302.00 | |
| AT-1250-8/30-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-8/30-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-8/32-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-8/32-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-8/34-4T37-F300 | 1250.00 | 37.00 | 66.00 | 206.00 | 276.00 | 351.00 | |
| AT-1250-8/34-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-8/34-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-8/36-4T45-F300 | 1250.00 | 45.00 | 80.00 | 232.00 | 302.00 | 377.00 | |
| AT-1250-8/36-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-8/38-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-8/38-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/40-4T55-F300 | 1250.00 | 55.00 | 100.00 | 385.00 | 455.00 | 530.00 | |
| AT-1250-8/40-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/42-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/42-4T90-F300 | 1250.00 | 90.00 | 159.00 | 570.00 | 640.00 | 715.00 | |
| AT-1250-8/44-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/44-4T90-F300 | 1250.00 | 90.00 | 159.00 | 570.00 | 640.00 | 715.00 | |
| AT-1250-8/46-4T75-F300 | 1250.00 | 75.00 | 134.00 | 440.00 | 510.00 | 585.00 | |
| AT-1250-8/46-4T90-F300 | 1250.00 | 90.00 | 159.00 | 570.00 | 640.00 | 715.00 | |
| AT-1400-4/24-4T18.5-F300 | 1400.00 | 18.50 | 35.50 | 113.00 | 244.00 | 334.00 | |
| AT-1400-4/24-4T22-F300 | 1400.00 | 22.00 | 41.50 | 123.00 | 254.00 | 344.00 | |
| AT-1400-4/26-4T18.5-F300 | 1400.00 | 18.50 | 35.50 | 113.00 | 244.00 | 334.00 | |
| AT-1400-4/26-4T22-F300 | 1400.00 | 22.00 | 41.50 | 123.00 | 254.00 | 344.00 | |
| AT-1400-4/26-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-4/28-4T22-F300 | 1400.00 | 22.00 | 41.50 | 123.00 | 254.00 | 344.00 | |
| AT-1400-4/28-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-4/30-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-4/30-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-4/32-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-4/32-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-4/32-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-4/34-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-4/34-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-4/36-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-4/36-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-4/38-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-4/38-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-4/38-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/40-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-4/40-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/42-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/44-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/44-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-4/46-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/46-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-4/48-4T110-F300 | 1400.00 | 110.00 | 195.00 | 740.00 | 871.00 | 961.00 | |
| AT-1400-4/48-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-4/48-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/24-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-8/24-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-8/26-4T30-F300 | 1400.00 | 30.00 | 55.00 | 157.00 | 288.00 | 378.00 | |
| AT-1400-8/26-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-8/26-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-8/28-4T37-F300 | 1400.00 | 37.00 | 66.00 | 206.00 | 337.00 | 427.00 | |
| AT-1400-8/28-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-8/30-4T45-F300 | 1400.00 | 45.00 | 80.00 | 232.00 | 363.00 | 453.00 | |
| AT-1400-8/30-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-8/32-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-8/32-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-8/34-4T55-F300 | 1400.00 | 55.00 | 100.00 | 385.00 | 516.00 | 606.00 | |
| AT-1400-8/34-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-8/36-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-8/36-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/38-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-8/38-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/40-4T110-F300 | 1400.00 | 110.00 | 195.00 | 740.00 | 871.00 | 961.00 | |
| AT-1400-8/40-4T75-F300 | 1400.00 | 75.00 | 134.00 | 440.00 | 571.00 | 661.00 | |
| AT-1400-8/40-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/42-4T110-F300 | 1400.00 | 110.00 | 195.00 | 740.00 | 871.00 | 961.00 | |
| AT-1400-8/42-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/44-4T110-F300 | 1400.00 | 110.00 | 195.00 | 740.00 | 871.00 | 961.00 | |
| AT-1400-8/44-4T90-F300 | 1400.00 | 90.00 | 159.00 | 570.00 | 701.00 | 791.00 | |
| AT-1400-8/46-4T110-F300 | 1400.00 | 110.00 | 195.00 | 740.00 | 871.00 | 961.00 | |
| AT-1400-8/48-4T132-F300 | 1400.00 | 132.00 | 230.00 | 870.00 | 1001.00 | 1091.00 | |
| AT-315-4/25-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-4/30-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-4/35-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-4/40-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-4/45-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-8/25-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-8/30-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-8/35-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-8/40-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-315-8/45-4T0.55-F300 | 315.00 | 0.55 | 1.46 | 9.00 | 13.00 | 15.00 | |
| AT-355-4/25-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-4/30-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-4/35-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-4/40-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-4/45-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-8/25-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-8/30-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-8/35-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-8/40-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-355-8/45-4T0.55-F300 | 355.00 | 0.55 | 1.46 | 9.00 | 13.50 | 15.00 | |
| AT-400-4/25-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-4/30-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-4/35-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-4/40-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-4/45-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-8/25-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-8/30-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-8/35-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-8/40-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-400-8/45-4T0.55-F300 | 400.00 | 0.55 | 1.46 | 9.00 | 17.50 | 21.00 | |
| AT-450-4/25-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-4/30-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-4/35-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-4/40-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-4/45-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-8/25-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-8/30-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-8/35-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-8/40-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-450-8/45-4T0.55-F300 | 450.00 | 0.55 | 1.46 | 9.00 | 18.50 | 25.00 | |
| AT-500-4/25-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-4/30-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-4/35-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-4/40-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-4/45-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-8/25-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-8/30-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-8/35-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-8/40-4T0.55-F300 | 500.00 | 0.55 | 1.46 | 9.00 | 20.00 | 27.00 | |
| AT-500-8/45-4T0.75-F300 | 500.00 | 0.75 | 1.91 | 10.00 | 21.00 | 28.00 | |
| AT-560-3/20-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-3/25-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-3/32.5-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-3/35-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-3/35-4T0.75-F300 | 560.00 | 0.75 | 1.91 | 10.00 | 23.20 | 34.00 | |
| AT-560-3/37.5-4T0.75-F300 | 560.00 | 0.75 | 1.91 | 10.00 | 23.20 | 34.00 | |
| AT-560-3/40-4T0.75-F300 | 560.00 | 0.75 | 1.91 | 10.00 | 23.20 | 34.00 | |
| AT-560-3/40-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-3/45-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-6/20-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-6/25-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-6/30-4T0.75-F300 | 560.00 | 0.75 | 1.91 | 10.00 | 23.20 | 34.00 | |
| AT-560-6/32.5-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-6/35-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-6/37.5-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-6/40-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-6/40-4T1.5-F300 | 560.00 | 1.50 | 3.40 | 15.60 | 28.80 | 39.60 | |
| AT-560-6/45-4T1.5-F300 | 560.00 | 1.50 | 3.40 | 15.60 | 28.80 | 39.60 | |
| AT-560-9/20-4T0.55-F300 | 560.00 | 0.55 | 1.46 | 9.00 | 22.20 | 33.00 | |
| AT-560-9/25-4T0.75-F300 | 560.00 | 0.75 | 1.91 | 10.00 | 23.20 | 34.00 | |
| AT-560-9/30-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-9/32.5-4T1.1-F300 | 560.00 | 1.10 | 2.55 | 13.00 | 26.20 | 37.00 | |
| AT-560-9/35-4T1.5-F300 | 560.00 | 1.50 | 3.40 | 15.60 | 28.80 | 39.60 | |
| AT-560-9/37.5-4T1.5-F300 | 560.00 | 1.50 | 3.40 | 15.60 | 28.80 | 39.60 | |
| AT-560-9/40-4T1.5-F300 | 560.00 | 1.50 | 3.40 | 15.60 | 28.80 | 39.60 | |
| AT-560-9/45-4T2.2-F300 | 560.00 | 2.20 | 4.70 | 21.00 | 34.20 | 45.00 | |
| AT-630-3/20-4T0.55-F300 | 630.00 | 0.55 | 1.46 | 9.00 | 24.00 | 33.00 | |
| AT-630-3/25-4T0.55-F300 | 630.00 | 0.55 | 1.46 | 9.00 | 24.00 | 33.00 | |
| AT-630-3/30-4T0.55-F300 | 630.00 | 0.55 | 1.46 | 9.00 | 24.00 | 33.00 | |
| AT-630-3/30-4T0.75-F300 | 630.00 | 0.75 | 1.91 | 10.00 | 25.00 | 34.00 | |
| AT-630-3/32.5-4T0.75-F300 | 630.00 | 0.75 | 1.91 | 10.00 | 25.00 | 34.00 | |
| AT-630-3/35-4T0.75-F300 | 630.00 | 0.75 | 1.91 | 10.00 | 25.00 | 34.00 | |
| AT-630-3/35-4T1.1-F300 | 630.00 | 1.10 | 2.55 | 13.00 | 28.00 | 37.00 | |
| AT-630-3/37.5-4T1.1-F300 | 630.00 | 1.10 | 2.55 | 13.00 | 28.00 | 37.00 | |
| AT-630-3/40-4T1.1-F300 | 630.00 | 1.10 | 2.55 | 13.00 | 28.00 | 37.00 | |
| AT-630-3/40-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-3/45-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-6/20-4T0.55-F300 | 630.00 | 0.55 | 1.46 | 9.00 | 24.00 | 33.00 | |
| AT-630-6/25-4T0.75-F300 | 630.00 | 0.75 | 1.91 | 10.00 | 25.00 | 34.00 | |
| AT-630-6/30-4T1.1-F300 | 630.00 | 1.10 | 2.55 | 13.00 | 28.00 | 37.00 | |
| AT-630-6/32.5-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-6/35-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-6/37.5-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-6/37.5-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-6/40-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-6/45-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-9/20-4T0.75-F300 | 630.00 | 0.75 | 1.91 | 10.00 | 25.00 | 34.00 | |
| AT-630-9/25-4T1.1-F300 | 630.00 | 1.10 | 2.55 | 13.00 | 28.00 | 37.00 | |
| AT-630-9/30-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-9/32.5-4T1.5-F300 | 630.00 | 1.50 | 3.40 | 15.60 | 30.60 | 39.60 | |
| AT-630-9/32.5-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-9/35-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-9/37.5-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-9/40-4T2.2-F300 | 630.00 | 2.20 | 4.70 | 21.00 | 36.00 | 45.00 | |
| AT-630-9/40-4T3-F300 | 630.00 | 3.00 | 6.40 | 24.00 | 39.00 | 48.00 | |
| AT-630-9/45-4T3-F300 | 630.00 | 3.00 | 6.40 | 24.00 | 39.00 | 48.00 | |
| AT-710-3/20-4T0.55-F300 | 710.00 | 0.55 | 1.46 | 9.00 | 30.00 | 40.00 | |
| AT-710-3/25-4T0.55-F300 | 710.00 | 0.55 | 1.46 | 9.00 | 30.00 | 40.00 | |
| AT-710-3/25-4T0.75-F300 | 710.00 | 0.75 | 1.91 | 10.00 | 31.00 | 41.00 | |
| AT-710-3/30-4T0.75-F300 | 710.00 | 0.75 | 1.91 | 10.00 | 31.00 | 41.00 | |
| AT-710-3/30-4T1.1-F300 | 710.00 | 1.10 | 2.55 | 13.00 | 34.00 | 44.00 | |
| AT-710-3/32.5-4T1.1-F300 | 710.00 | 1.10 | 2.55 | 13.00 | 34.00 | 44.00 | |
| AT-710-3/35-4T1.1-F300 | 710.00 | 1.10 | 2.55 | 13.00 | 34.00 | 44.00 | |
| AT-710-3/37.5-4T1.5-F300 | 710.00 | 1.50 | 3.40 | 15.60 | 36.60 | 46.60 | |
| AT-710-3/40-4T1.5-F300 | 710.00 | 1.50 | 3.40 | 15.60 | 36.60 | 46.60 | |
| AT-710-3/45-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-6/20-4T0.75-F300 | 710.00 | 0.75 | 1.91 | 10.00 | 31.00 | 41.00 | |
| AT-710-6/25-4T1.1-F300 | 710.00 | 1.10 | 2.55 | 13.00 | 34.00 | 44.00 | |
| AT-710-6/30-4T1.5-F300 | 710.00 | 1.50 | 3.40 | 15.60 | 36.60 | 46.60 | |
| AT-710-6/30-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-6/32.5-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-6/35-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-6/37.5-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-6/37.5-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-6/40-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-6/45-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-6/45-4T4-F300 | 710.00 | 4.00 | 8.20 | 31.00 | 52.00 | 62.00 | |
| AT-710-9/20-4T1.1-F300 | 710.00 | 1.10 | 2.55 | 13.00 | 34.00 | 44.00 | |
| AT-710-9/25-4T1.5-F300 | 710.00 | 1.50 | 3.40 | 15.60 | 36.60 | 46.60 | |
| AT-710-9/30-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-9/32.5-4T2.2-F300 | 710.00 | 2.20 | 4.70 | 21.00 | 42.00 | 52.00 | |
| AT-710-9/32.5-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-9/35-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-9/37.5-4T3-F300 | 710.00 | 3.00 | 6.40 | 24.00 | 45.00 | 55.00 | |
| AT-710-9/37.5-4T4-F300 | 710.00 | 4.00 | 8.20 | 31.00 | 52.00 | 62.00 | |
| AT-710-9/40-4T4-F300 | 710.00 | 4.00 | 8.20 | 31.00 | 52.00 | 62.00 | |
| AT-710-9/45-4T4-F300 | 710.00 | 4.00 | 8.20 | 31.00 | 52.00 | 62.00 | |
| AT-710-9/45-4T5.5-F300 | 710.00 | 5.50 | 11.40 | 41.00 | 62.00 | 72.00 | |
| AT-800-3/20-4T0.55-F300 | 800.00 | 0.55 | 1.46 | 9.00 | 45.00 | 62.00 | |
| AT-800-3/25-4T1.1-F300 | 800.00 | 1.10 | 2.55 | 13.00 | 49.00 | 66.00 | |
| AT-800-3/30-4T1.5-F300 | 800.00 | 1.50 | 3.40 | 15.60 | 51.60 | 68.60 | |
| AT-800-3/32.5-4T1.5-F300 | 800.00 | 1.50 | 3.40 | 15.60 | 51.60 | 68.60 | |
| AT-800-3/35-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-3/37.5-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-3/40-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-3/45-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-6/20-4T1.1-F300 | 800.00 | 1.10 | 2.55 | 13.00 | 49.00 | 66.00 | |
| AT-800-6/25-4T1.5-F300 | 800.00 | 1.50 | 3.40 | 15.60 | 51.60 | 68.60 | |
| AT-800-6/25-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-6/30-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-6/30-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-6/32.5-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-6/35-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-6/35-4T4-F300 | 800.00 | 4.00 | 8.20 | 31.00 | 67.00 | 84.00 | |
| AT-800-6/37.5-4T4-F300 | 800.00 | 4.00 | 8.20 | 31.00 | 67.00 | 84.00 | |
| AT-800-6/40-4T4-F300 | 800.00 | 4.00 | 8.20 | 31.00 | 67.00 | 84.00 | |
| AT-800-6/45-4T5.5-F300 | 800.00 | 5.50 | 11.40 | 41.00 | 77.00 | 94.00 | |
| AT-800-9/20-4T1.5-F300 | 800.00 | 1.50 | 3.40 | 15.60 | 51.60 | 68.60 | |
| AT-800-9/20-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-9/25-4T2.2-F300 | 800.00 | 2.20 | 4.70 | 21.00 | 57.00 | 74.00 | |
| AT-800-9/25-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-9/30-4T3-F300 | 800.00 | 3.00 | 6.40 | 24.00 | 60.00 | 77.00 | |
| AT-800-9/30-4T4-F300 | 800.00 | 4.00 | 8.20 | 31.00 | 67.00 | 84.00 | |
| AT-800-9/32.5-4T4-F300 | 800.00 | 4.00 | 8.20 | 31.00 | 67.00 | 84.00 | |
| AT-800-9/35-4T5.5-F300 | 800.00 | 5.50 | 11.40 | 41.00 | 77.00 | 94.00 | |
| AT-800-9/37.5-4T5.5-F300 | 800.00 | 5.50 | 11.40 | 41.00 | 77.00 | 94.00 | |
| AT-800-9/40-4T5.5-F300 | 800.00 | 5.50 | 11.40 | 41.00 | 77.00 | 94.00 | |
| AT-800-9/45-4T7.5-F300 | 800.00 | 7.50 | 15.20 | 49.00 | 85.00 | 102.00 | |
| AT-900-3/27.5-4T2.2-F300 | 900.00 | 2.20 | 4.70 | 21.00 | 68.00 | 91.00 | |
| AT-900-3/30-4T2.2-F300 | 900.00 | 2.20 | 4.70 | 21.00 | 68.00 | 91.00 | |
| AT-900-3/32.5-4T2.2-F300 | 900.00 | 2.20 | 4.70 | 21.00 | 68.00 | 91.00 | |
| AT-900-3/32.5-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-3/35-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-3/37.5-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-3/37.5-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-3/40-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-3/40-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-3/42.5-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-3/45-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-3/47.5-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-3/47.5-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-3/50-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-6/25-4T2.2-F300 | 900.00 | 2.20 | 4.70 | 21.00 | 68.00 | 91.00 | |
| AT-900-6/27.5-4T2.2-F300 | 900.00 | 2.20 | 4.70 | 21.00 | 68.00 | 91.00 | |
| AT-900-6/27.5-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-6/30-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-6/30-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-6/32.5-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-6/32.5-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-6/35-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-6/37.5-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-6/37.5-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-6/40-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-6/42.5-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-6/45-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-6/45-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-6/47.5-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-6/50-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-9/25-4T3-F300 | 900.00 | 3.00 | 6.40 | 24.00 | 71.00 | 94.00 | |
| AT-900-9/25-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-9/27.5-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-9/30-4T4-F300 | 900.00 | 4.00 | 8.20 | 31.00 | 78.00 | 101.00 | |
| AT-900-9/30-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-9/32.5-4T5.5-F300 | 900.00 | 5.50 | 11.40 | 41.00 | 88.00 | 111.00 | |
| AT-900-9/35-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-9/37.5-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-9/40-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-9/40-4T7.5-F300 | 900.00 | 7.50 | 15.20 | 49.00 | 96.00 | 119.00 | |
| AT-900-9/42.5-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-9/45-4T11-F300 | 900.00 | 11.00 | 21.50 | 73.00 | 120.00 | 143.00 | |
| AT-900-9/47.5-4T15-F300 | 900.00 | 15.00 | 28.50 | 85.00 | 132.00 | 155.00 | |
| AT-900-9/50-4T15-F300 | 900.00 | 15.00 | 28.50 | 85.00 | 132.00 | 155.00 | |
Related products
Roof Ventilator Axial Fan
Roof Ventilator Axial Fan RATH series are designed for exhaust smoke from atriums and industrial ...
انگلیس
Manufacturing Country
Roof Ventilator Centrifugal Fan
Roof Ventilator Centrifugal Fan RCRH series are designed for exhaust smoke from warehouse, atrium...
Turkey
Manufacturing Country
Roof Ventilator Centrifugal Fan
Roof Ventilator Centrifugal Fan RC series are designed for exhaust of air in commercial, industri...
Turkey
Manufacturing Country
Roof Ventilator Centrifugal Fan
Roof Ventilator Centrifugal Fan RCR series are designed for exhaust of air in commercial, industr...
Turkey
Manufacturing Country
EFCCS series Concealed Ceiling Slim Fan Coils
EFCC series Concealed ceiling Slim fan coils are produced for use cooling and heating of office, ...
Turkey
Manufacturing Country
Process Air Cooler Series APSX
The best choice for process air coolers & cooling towers In different sizes from 1400 to 3500...
Turkey
Manufacturing Country
Ventilator S&P model DECOR-100 C
S&P Spain company is the largest company in the world in the direction of production and desi...
Manufacturing Country
MyAir air purifier series FU-2000-H14/CA/UV
MyAir FU-2000-H14/CA/UV series air purifier with HEPA filter, UVC lamps and active carbon filter ...
England
Manufacturing Country
