JAFH Series Axial Jet Fans
- 25 ~ 145 N thrust range
- High efficiency aerodynamic blades
- 315 ~ 500 mm diameter range
- 300°C fire resistance certificate in compliance with EN 12101-3
- Galvanized sheet casing
- Diecast aluminum fan blades
- Ability to work reversible (on request)
- 2/4 pole double speed motor
- Insulation class H motor
- IP55 Protection class
JAFH series axial jet fans use aerodynamic blades with high efficiency. The material of the body is galvanized and its aluminum propellers are responsible for air circulation and transmission. These fans have the ability to work in a reversible way and their limited thrust is 25 to 145 newtons.
| Model | Thrust (N) | Motor Power (kW) | Current (A) | Motor Speed (rpm) | Noise @ 3m (dBA) |
|---|---|---|---|---|---|
| JAFH-315-2/4T | 25.00 | 0,8/0,2 | 1,9/0,6 | 2820/1400 | 64/49±3 |
| JAFH-355-2/4T | 45.00 | 1,1/0,25 | 2,4/0,75 | 2810/1390 | 67/52±3 |
| JAFH-400-2/4T | 70.00 | 1,5/0,37 | 3,5/1,3 | 2900/1435 | 71/56±3 |
| JAFH-450-2/4T | 105.00 | 2,2/0,5 | 4,6/1,5 | 2845/1420 | 75/60±3 |
| JAFH-500-2/4T | 145.00 | 4.4/1.1 | 8,6/2,8 | 2890/1440 | 78/63±3 |
