Smoke Curtain
- Separation of smoke zones from each other
- Made of glass fiber reinforced with steel wires and polyurethane coating.
Smoke curtains mostly constructed without guides are usually used in places to separate the smoke zones. The fabric characteristics of these curtains are similar to fire curtains, which are made of glass fiber, reinforced with stainless steel wire, and coated with a formulated fire retardant aluminum pigment-ed polyurethane coating. Certificates and approvals of these curtains are measured according to the standard EN BS 12101-1 and have two main groups of curtains general and fire rated. General curtains are tested at 600°C, but DAX curtains are tested at fire temperature. The leakage of these curtains, which is very important to prevent the movement of smoke, is also measured during the test.
Name | Model |
---|---|
Smoke Curtain | SB-D180 |
Smoke Curtain-Fire Rated | SBF-DH180 |
Smoke Curtain-CIRCULAR BOTTOM | SBC-D180 |
Smoke Curtain-Horizontal | SBH-D120 |
